Description
SE47.1 (BIM) — Interface Module
Siemens · SE47.1 (BIM) · 6DD1681-0EH1
Description
The bus interface module (BIM) SE47.1, order no. 6DD1681-0EH1, is an interface module for the SIMADYN D control system enabling communication over the DUST 4 (fiber-optic distributed peripheral) bus at a data rate of 1 Mbit/s.
Key specifications
Parameter | Value |
Function | Bus interface module (BIM) for DUST 4 communication in SIMADYN D |
Data rate | 1 Mbit/s |
Network | DUST 4 (distributed peripheral bus) |
Mounting/Rack | SIMADYN D subrack slot, plug-in board |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | SE47.1 (BIM) |
Part number | 6DD1681-0EH1 |
Category | Interface Module |
System family | SIMADYN D |
Stores quantity | 11 |
Data confidence | high |
Manuals filed (007 - Manuals)
- Simadyn D Hardw_e new 32bit.pdf — SIMADYN D hardware manual (English) covering PM/MS/MM/EM/CS/SP module family
- 19_00_Simadyn_D_Control_System.pdf — SIMADYN D control-system overview
Notes
Verified via Siemens SIMADYN D Interface module SE47.1 datasheet (ADEGIS-hosted PDF).
Source: Spare Parts List for Sales V7 (Bohemia Market / BM Global stores inventory). Filed in the AI HW Knowledge Base.
