ADD7 FEM (AddFEM) — Interface
Siemens · ADD7 FEM (AddFEM) · 6DL3100-8AA
Description
The AddFEM (Add 7 Front End Module) is a rugged field electronics module purpose-built for fast turbine control (gas, steam, industrial, and water turbines), providing a rich mix of analog/digital I/O and speed-sensing inputs directly on a PROFIBUS-DP slave interface. It can be used with SIMATIC S7/PCS 7, SPPA-T3000, or SIMADYN D automation processors, with the controlling logic typically implemented in the host automation processor rather than on the AddFEM itself.
Key specifications
Parameter | Value |
Function | PROFIBUS-DP slave front-end module for fast turbine control I/O |
Analog inputs | 12 AI (6 current-only, 6 configurable current/voltage) |
Analog outputs | 8 AO |
Digital inputs | 15 DI (3 usable as speed/counter inputs with/without direction detection) |
Digital outputs | 16 DO (500 mA each, also usable as DI) |
Power supply | 24 V DC, 19.2-30.2 V permissible range; module supply 0.8 A, load supply up to 8 A |
Bus interface | PROFIBUS-DP (DPV1 services per IEC 61158-3/6; 6DL3100-8AA is the base/non-DPV1-parameterizable variant) |
Dimensions/weight | 295 x 75 x 209 mm; ~2.8 kg |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | ADD7 FEM (AddFEM) |
Part number | 6DL3100-8AA |
Category | Interface |
System family | SIMADYN D / Add 7 |
GT stores quantity | 12 |
Data confidence | high |
Manuals filed (007 - Manuals)
- C79000-G8076-C900-03.pdf — Exact-match AddFEM manual filed under the 6DL3100-8AA English documentation folder
- Readme.pdf (ADD 7 FEM) — Top-level ADD 7 FEM documentation readme
Notes
Exact Drive manual match found for this precise part number/folder structure; specs cross-verified against the Siemens AddFEM manual (cache.industry.siemens.com) and reseller/distributor pages (ArtisanTG, Scribd).
