AI 465-4 — Analog Input Module
Siemens · AI 465-4 · 6ES5465-4UA12
Description
SIMATIC S5 465 analog input module, compact 'U' version, for S5-135U/-155U/H PLCs. Provides 16 or 8 current/voltage analog input channels, non-floating, and requires a 498-series measuring range module for the selected input range.
Key specifications
Parameter | Value |
Function | Analog input, current/voltage, non-floating |
Channels | 16 (or 8, depending on range module used) |
Compatible controllers | S5-135U, S5-155U/H |
Measuring range module | Requires 6ES5498-1AAx1 range module |
Mounting/Rack | S5-135U/155U CR/ER rack |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | AI 465-4 |
Part number | 6ES5465-4UA12 |
Category | Analog I/O |
System family | SIMATIC S5-135U/155U |
Stores quantity | 10 |
Data confidence | high |
Manuals filed (007 - Manuals)
- Manual CP1430 English Vol1.pdf — S5-115U system reference (CP/comms volume)
- 02 - CPU948 Programming Manual.pdf — S5 CPU programming reference (115U/155H family)
Notes
Confirmed via 4dcontrols and sps-service datasheets for exact order number.
Source: Spare Parts List for Sales V7 (Bohemia Market / BM Global stores inventory). Filed in the AI HW Knowledge Base.
