482 Digital I/O (mixed DI/DO) — Digital I/O
Siemens · 482 Digital I/O (mixed DI/DO) · 6ES5482-UA20
Description
The 482-series module is a compact mixed digital input/output module for the S5-100U I/O system, combining digital inputs and outputs on a single module for space-constrained applications. The inventoried part number "6ES5482-UA20" is not a valid/complete Siemens order pattern; the corrected family designation is 6ES5482-8MAxx (matching the confirmed gt14 mixed I/O module in this same inventory).
Key specifications
Parameter | Value |
Function | Combined digital input/output module, S5-100U |
Module family | 6ES5 482-8MAxx mixed DI/DO for S5-100U |
Rated voltage | 24 V DC (typical of 48x-series S5-100U I/O) |
Mounting | S5-100U I/O rail-mount module |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | 482 Digital I/O (mixed DI/DO) |
Part number | 6ES5482-UA20 |
Category | Digital I/O |
System family | S5-100U |
GT stores quantity | 9 |
Data confidence | low |
Manuals filed (007 - Manuals)
- Manual STEP5 S5-100U English.PDF — S5-100U reference manual covering 4xx I/O module family including 482 combined I/O
Notes
Per the research brief, "6ES5482-UA20" as inventoried is almost certainly a truncated/garbled order number. It most likely belongs to the same 6ES5482-8MAxx mixed-I/O family as gt14 (6ES5482-8MA13), but the exact suffix/channel count could not be independently confirmed — verify against the physical module label before treating as a distinct catalog variant. [PN CORRECTION: kept as-inventoried 6ES5482-UA20; this token is uncertain/garbled and could not be confirmed on siemens.com. gt14 is the confirmed 6ES5482-8MA13 DI/DO module. gt08 retained as a distinct inventory line pending physical label verification.]
Source: Sohar 1 DCS field-component stores inventory (Total GT_BOP). Filed in the AI HW Knowledge Base.
