DE 09P064 TX — Connector
Siemens · DE 09P064 TX · 6ES5750-2AA11
Description
SIMATIC S5 9-pin Sub-D plug connector (DE-9 type), used for serial/programming interface connections such as PG/COM ports on S5 CPUs and communication modules.
Key specifications
Parameter | Value |
Function | 9-pin D-sub (DE-9) plug connector |
Pin count | 9 |
Application | Serial/programming interface (COM/PG port) |
Connector type | Male plug |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | DE 09P064 TX |
Part number | 6ES5750-2AA11 |
Category | Connector/Cable |
System family | SIMATIC S5 |
Stores quantity | 7 |
Data confidence | medium |
Manuals filed (007 - Manuals)
- Manual CP1430 English Vol1.pdf — S5-115U system reference (CP/comms volume)
- 02 - CPU948 Programming Manual.pdf — S5 CPU programming reference (115U/155H family)
Notes
Identified as standard 9-pin D-sub connector per description (DE 09P064 TX); exact Siemens datasheet for order number not independently located, classification based on standard DE-9 connector convention.
Source: Spare Parts List for Sales V7 (Bohemia Market / BM Global stores inventory). Filed in the AI HW Knowledge Base.
