CP 1430 TF — Communication Processor
Siemens (SIMATIC NET) · CP 1430 TF · 6GK1143-0TB01
Description
The CP 1430 TF is a communication processor card providing an Industrial Ethernet (SINEC H1/TF, ISO Transport) interface for S5-135U/155U central controllers, enabling host-to-host communication over Ethernet using the TF (Transport interFace) protocol per ISO 8073.
Key specifications
Parameter | Value |
Function | Industrial Ethernet communications processor (SINEC H1, TF/ISO transport) |
Protocol | ISO Transport (TF), SINEC H1 |
Bus interface | AUI / Ethernet coax (per SINEC H1 era hardware) |
Host system | S5-135U/155U central rack |
Typical use | Peer-to-peer data exchange between S5 CPUs and host computers over Ethernet |
Reference
Field | Value |
Manufacturer (OEM) | Siemens (SIMATIC NET) |
Model | CP 1430 TF |
Part number | 6GK1143-0TB01 |
Category | Communication |
System family | SIMATIC NET / Industrial Ethernet |
GT stores quantity | 18 |
Data confidence | high |
Manuals filed (007 - Manuals)
- Manual CP1430 English Vol1.pdf — Direct CP1430 manual, Volume 1 — exact model match
- Manual CP1430 English Vol2.pdf — Direct CP1430 manual, Volume 2 — exact model match
Notes
Direct manual matches found in Drive specific to the CP 1430 model.
Source: Sohar 1 DCS field-component stores inventory (Total GT_BOP). Filed in the AI HW Knowledge Base.
