Description
727-1 SINEC H1 Cable — Cable
Siemens · 727-1 SINEC H1 Cable · 6ES5727-1CC00
Description
SIMATIC NET SINEC H1 triaxial bus cable (727-series), used for Industrial Ethernet (SINEC H1) network segments compliant with IEEE 802.3, requiring 50-ohm termination at each end. Supplied length 20 m.
Key specifications
Parameter | Value |
Function | SINEC H1 (Industrial Ethernet) triaxial bus cable |
Length | 20 m |
Standard | IEEE 802.3 compliant |
Termination | 50-ohm terminating resistor at each segment end |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | 727-1 SINEC H1 Cable |
Part number | 6ES5727-1CC00 |
Category | Connector/Cable |
System family | SIMATIC NET / SINEC |
Stores quantity | 5 |
Data confidence | medium |
Manuals filed (007 - Manuals)
- hb89e_cp143_00-07.pdf — CP143 SINEC H1 communication processor manual (English)
- Manual CP1430 English Vol1.pdf — SINEC CP1430/CP143x communication processor manual Vol 1
- SINEC_CP1430TF_Vol.1_e.pdf — SINEC CP1430 TF communication processor manual (English)
Notes
SINEC H1 727-series triaxial cable confirmed via ADEGIS SIMATIC NET catalog; exact -1CC00 length-suffix datasheet not independently located but 20m length matches inventoried desc.
Source: Spare Parts List for Sales V7 (Bohemia Market / BM Global stores inventory). Filed in the AI HW Knowledge Base.
