AI 464 — Analog Input Module
Siemens · AI 464 · 6ES5464-8MF21
Description
SIMATIC S5 module 464 analog input, isolated version for S5-90U/-95U/-100U, ET 100U and ET 200U. Provides 2 inputs for Pt100 RTD sensors with linearization for temperature measurement.
Key specifications
Parameter | Value |
Function | 2x isolated analog inputs, Pt100 RTD with linearization |
Compatible controllers | S5-90U, S5-95U, S5-100U, ET 100U, ET 200U |
Channels | 2 |
Signal type | Pt100 resistance thermometer |
Mounting/Rack | S5-100U I/O rack slot |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | AI 464 |
Part number | 6ES5464-8MF21 |
Category | Analog I/O |
System family | SIMATIC S5-100U |
Stores quantity | 28 |
Data confidence | high |
Manuals filed (007 - Manuals)
- Manual STEP5 S5-100U English.PDF — S5-100U system manual (English) covering CPU/IO/memory for the 100U programmable controller
Notes
Confirmed via vendor datasheets (Polrad, 4D Controls) matching exact order number.
