DO 440 — Digital Output Module
Siemens · DO 440 · 6ES5440-8MA22
Description
The DO 440 (6ES5440-8MA22, version 1) is a digital output module for the SIMATIC S5-90U/95U/100U, ET 100U, and ET 200U systems, providing 4 digital outputs at 24V DC with 2A per channel; this is a later revision of the 6ES5440-8MA21 module.
Key specifications
Parameter | Value |
Function | Digital output module for S5-90U/95U/100U, ET100U, ET200U |
Channels | 4 digital outputs |
Output rating | 24 V DC, 2 A per channel |
Isolation | Non-floating (common ground) |
Loads | Suitable for 10W tungsten lamp load, 2A resistive |
Reference
Field | Value |
Manufacturer (OEM) | Siemens |
Model | DO 440 |
Part number | 6ES5440-8MA22 |
Category | Digital I/O |
System family | SIMATIC S5-90U/95U/100U |
Stores quantity | 5 |
Data confidence | high |
Manuals filed (007 - Manuals)
- Manual STEP5 S5-100U English.PDF — S5-100U system manual (English) covering CPU/IO/memory for the 100U programmable controller
Notes
Verified via auto2mation.com and 6es7.pl (Polrad) listings confirming DO 440-8MA22 = 4x24VDC/2A output module, version revision of -8MA21.
